It is recommended that AF-90 be applied to a maximum thickness of 25mm, as greater applications do not result in any significant acoustic performance beyond an NRC ( Noise Reduction Coeff) of 0.90.
Typically, an optimum thickness of 15mm (NRC 0.65) applied to 70% of available ceiling areas, would offer brilliant reverberation control in most open plan office situations, including Call Centre.
Efficient application is achieved by a crew consisting of 3-4 workers, consisting of: One Sprayer, one Machine Feeder and one (or more) Cleaners to maintain good site housekeeping.
AF-90 is available in an illuminating “Vivid White”, and may be colour dyed on Site, or over painted with an acrylic paint, to achieve a specific final look.
This is best used in areas where a chic smart looking acoustic ceiling / soffit is required- making it highly suitable for restaurants, meeting rooms, open plan offices, libraries and Call Centres.
AF-90 may be used in any building, with or without a sprinkler system complying with Specification E 1.5 in accordance with Specification C 1.10 Table 2.
Tested Standards | ||
---|---|---|
AS 1530.3 | Spread of Flame Index | : 0 |
Smoke Developed Index | : 2 | |
AS 3837 | Heat & Smoke Release | : Group 1 |
Specific Extinction Area | : 44.5 m2 /kg | |
ASTM C-518 | Thermal Resistance R | : 0.65 @ 25 mm |
Thermal Conductivity λ | : 0.0390 W/m.oK | |
ASTM E-136 | Non Combustible | : Yes |
ASTM C-423 | Noise Reduction Coeff (12mm) | : NRC 0.60 |
ASTM C-423 | Noise Reduction Coeff (25mm ) | : NRC 0.90 |
MIL-STD 810E | Fungal Resistance | : No growth |
AS 4859.1 | Compliance | : Yes |
ASTM-E759-92 (Reapproved 2011) | Seismic Compliance | : Yes |
